1073540-DB | Bucket Edge Center

SKU: 1073540
Regular price $1,146.77

Bolt-on cutting edges have moderate impact resistance to allow them to perform across a variety of applications boosting your machines versatility. They are designed to reduce the time required to replace your cutting edges, increase bucket capacity, and reduce downtime by maintaining a long wear.

Model Number 980
Series Number G H
Configuration Coal
Serial Number 2636334
Blade Position HD Center
Blade Thickness 2
Blade Width 19
Blade Length 52.438
Hole Quantity 9
Bolt Diameter 1.25
First Hole Distance From End in Inches 2.48
Second Hole Distance From First Hole in Inches 3.346
Third Hole Distance From Second Hole in Inches 3.346
Bolt Quantity for First Row of Holes 9
Bolt Length for First Row of Holes 3.75
Bolt Quantity for Second Row of Holes 0
Bolt Length for Second Row of Holes 0
Second Set of Holes First Hole Distance From End 0
Second Set of Holes Second Hole Distance From First Hole 0
Second Set of Holes Third Hole Distance From Second Hole 0
