Bolt-on cutting edges have moderate impact resistance to allow them to perform across a variety of applications boosting your machines versatility. They are designed to reduce the time required to replace your cutting edges, increase bucket capacity, and reduce downtime by maintaining a long wear.
Model Number | 980 |
---|---|
Series Number | F G H |
Configuration | Spade Nose Rock |
Serial Number | 1352959 1369033 1133254 1851569 1875298 1875322 |
Blade Position | Center |
Blade Thickness | 1.375 |
Blade Width | 16 |
Blade Length | 25 |
Hole Quantity | 5 |
Bolt Diameter | 1.25 |
First Hole Distance From End in Inches | 2.77 |
Second Hole Distance From First Hole in Inches | 6.38 |
Third Hole Distance From Second Hole in Inches | 3.35 |
Bolt Quantity for First Row of Holes | 5 |
Bolt Length for First Row of Holes | 3.75 |
Bolt Quantity for Second Row of Holes | 0 |
Bolt Length for Second Row of Holes | 0 |
Second Set of Holes First Hole Distance From End | 0 |
Second Set of Holes Second Hole Distance From First Hole | 0 |
Second Set of Holes Third Hole Distance From Second Hole | 0 |
