Protect your bucket with OEM quality cutting edges. They offer versatile and consistent protection, increase bucket capacity, reduce downtime, and are made from high-quality steel for long wear life. Choose OEM quality Ground Engaging Tools to protect your investment.
| Model Number | L110 |
|---|---|
| Series | E |
| Configuration | General Purpose |
| Serial Number | 93869 93870 93876 93872 93882 80145 80939 80941 82117 82360 |
| Blade Position | End |
| Blade Thickness | 1 |
| Blade Width | 18.17 |
| Blade Length | 24.56 |
| Hole Quantity | 10 |
| Bolt Diameter | 0.75 |
| First Hole Distance From End in Inches | 4.88 |
| Second Hole Distance From First Hole in Inches | 4.25 |
| Third Hole Distance From Second Hole in Inches | 3.15 |
| Bolt Quantity for First Row of Holes | 5 |
| Bolt Length for First Row of Holes | 3 |
| Bolt Quantity for Second Row of Holes | 2 |
| Bolt Length for Second Row of Holes | 3 |
| Second Set of Holes First Hole Distance From End | 4.88 |
| Second Set of Holes Second Hole Distance From First Hole | 4.25 |
| Second Set of Holes Third Hole Distance From Second Hole | 3.15 |
| Teeth Length | |
| Teeth Width | |
| Teeth Thickness | |
