Corner guards are weld-on, replaceable wear surfaces to protect bucket sides and lower bucket maintenance costs. Corner guards provide better bucket penetration, increase bucket width and headed capacity for bigger payloads and ultimately saving you both time and money.
| Model Number | 980 |
|---|---|
| Series Number | G H |
| Configuration | Coal |
| Serial Number | 2636334 |
| Blade Position | Segment LH |
| Blade Thickness | 1.5 |
| Blade Width | 19 |
| Blade Length | 19 |
| Hole Quantity | 3 |
| Bolt Diameter | 1.25 |
| First Hole Distance From End in Inches | 6.154 |
| Second Hole Distance From First Hole in Inches | 3.346 |
| Third Hole Distance From Second Hole in Inches | 3.346 |
| Bolt Quantity for First Row of Holes | 3 |
| Bolt Length for First Row of Holes | 3.75 |
| Bolt Quantity for Second Row of Holes | 0 |
| Bolt Length for Second Row of Holes | 0 |
| Second Set of Holes First Hole Distance From End | 0 |
| Second Set of Holes Second Hole Distance From First Hole | 0 |
| Second Set of Holes Third Hole Distance From Second Hole | 0 |
