Protect your bucket with OEM quality cutting edges. They offer versatile and consistent protection, increase bucket capacity, reduce downtime, and are made from high-quality steel for long wear life. Choose OEM quality Ground Engaging Tools to protect your investment.
| Model Number | D6 |
|---|---|
| Series Number | C D E G |
| Configuration | Angle |
| Serial Number | 54U 44E 47G 58G 18H |
| Blade Position | Hot Cup End Bit LH |
| Blade Thickness | 1.25 |
| Blade Width | 10.75 |
| Blade Length | 17.5 |
| Hole Quantity | 6 |
| Bolt Diameter | 0.75 |
| First Hole Distance From End in Inches | 2.25 |
| Second Hole Distance From First Hole in Inches | 3.188 |
| Third Hole Distance From Second Hole in Inches | 3.188 |
| Bolt Quantity for First Row of Holes | 3 |
| Bolt Length for First Row of Holes | 2.5 |
| Bolt Quantity for Second Row of Holes | 3 |
| Bolt Length for Second Row of Holes | 2.5 |
| Second Set of Holes First Hole Distance From End | 2.25 |
| Second Set of Holes Second Hole Distance From First Hole | 3.875 |
| Second Set of Holes Third Hole Distance From Second Hole | 3.625 |
