1.5" X 23.252" X 43.496" RH END BIT
| Model Number | 992 |
|---|---|
| Series Number | K |
| Configuration | Spade Nose Rock |
| Serial Number | 3146421 |
| Blade Position | Segment RH END |
| Blade Thickness | 1.5 |
| Blade Width | 23.252 |
| Blade Length | 43.496 |
| Hole Quantity | 8 |
| Bolt Diameter | 1.25 |
| First Hole Distance From End in Inches | 8.165 |
| Second Hole Distance From First Hole in Inches | 3.72 |
| Third Hole Distance From Second Hole in Inches | 3.839 |
| Bolt Quantity for First Row of Holes | 0 |
| Bolt Length for First Row of Holes | 0 |
| Bolt Quantity for Second Row of Holes | 0 |
| Bolt Length for Second Row of Holes | 0 |
| Second Set of Holes First Hole Distance From End | 0 |
| Second Set of Holes Second Hole Distance From First Hole | 0 |
| Second Set of Holes Third Hole Distance From Second Hole | 0 |
