.75" X 8" X 37.425" FOLDABLE END BIT
| Model Number | D6 |
|---|---|
| Series Number | K |
| Configuration | Foldable Power Angle Tilt XL & LGP |
| Serial Number | 2971700 |
| Blade Position | Dozer Foldable Side End Bit |
| Blade Thickness | 0.75 |
| Blade Width | 8 |
| Blade Length | 37.425 |
| Hole Quantity | 7 |
| Bolt Diameter | 0.75 |
| First Hole Distance From End in Inches | 5.906 |
| Second Hole Distance From First Hole in Inches | 3 |
| Third Hole Distance From Second Hole in Inches | 3 |
| Bolt Quantity for First Row of Holes | 7 |
| Bolt Length for First Row of Holes | 2.5 |
| Bolt Quantity for Second Row of Holes | 0 |
| Bolt Length for Second Row of Holes | 0 |
| Second Set of Holes First Hole Distance From End | 0 |
| Second Set of Holes Second Hole Distance From First Hole | 0 |
| Second Set of Holes Third Hole Distance From Second Hole | 0 |
