Bolt-on cutting edges have moderate impact resistance to allow them to perform across a variety of applications boosting your machines versatility. They are designed to reduce the time required to replace your cutting edges, increase bucket capacity, and reduce downtime by maintaining a long wear.
| Model Number | D7 |
|---|---|
| Series Number | H R |
| Configuration | Straight |
| Serial Number | 6KB 8ZB 4XC 8NH J8L CDC |
| Blade Position | Dozer Blade Support |
| Blade Thickness | 1.125 |
| Blade Width | 8.5 |
| Blade Length | 142.806 |
| Hole Quantity | 32 |
| Bolt Diameter | 0.938 |
| First Hole Distance From End in Inches | 6.153 |
| Second Hole Distance From First Hole in Inches | 3 |
| Third Hole Distance From Second Hole in Inches | 3 |
| Bolt Quantity for First Row of Holes | 0 |
| Bolt Length for First Row of Holes | 0 |
| Bolt Quantity for Second Row of Holes | 0 |
| Bolt Length for Second Row of Holes | 0 |
| Second Set of Holes First Hole Distance From End | 0 |
| Second Set of Holes Second Hole Distance From First Hole | 0 |
| Second Set of Holes Third Hole Distance From Second Hole | 0 |
