Bolt-on cutting edges have moderate impact resistance to allow them to perform across a variety of applications boosting your machines versatility. They are designed to reduce the time required to replace your cutting edges, increase bucket capacity, and reduce downtime by maintaining a long wear.
| Model Number | 980 |
|---|---|
| Series | F G |
| Configuration | Spade Nose Rock |
| Serial Number | 2Q2827 2Q2066 2Q2067 |
| Blade Position | Center LH |
| Blade Thickness | 1.375 |
| Blade Width | 16 |
| Blade Length | 32.875 |
| Hole Quantity | 4 |
| Bolt Diameter | 1.25 |
| First Hole Distance From End in Inches | 4.438 |
| Second Hole Distance From First Hole in Inches | 5.25 |
| Third Hole Distance From Second Hole in Inches | 13.5 |
| Bolt Quantity for First Row of Holes | 4 |
| Bolt Length for First Row of Holes | 3.75 |
| Bolt Quantity for Second Row of Holes | 0 |
| Bolt Length for Second Row of Holes | 0 |
| Second Set of Holes First Hole Distance From End | 0 |
| Second Set of Holes Second Hole Distance From First Hole | 0 |
| Second Set of Holes Third Hole Distance From Second Hole | 0 |
| Teeth Length | |
| Teeth Width | |
| Teeth Thickness | |
