08283234 | Level Cut End Bit RH

SKU: 8283234

Call for pricing - 870-536-0402

OEM quality end bits are highly effective in safeguarding the blade of your machines from damage, thanks to their unparalleled manufacturing precision. These end bits are designed to balance abrasion, impact resistance, and penetration ability in the best possible way. Moreover, their contoured design facilitates the rolling of material towards the center of the blade, thereby ensuring greater load retention and capacity. This, in turn, leads to increased productivity of the machine. Specifically, general duty end bits come with a sharpened profile and sit below the leading edge of the cutting edge, making them an excellent choice for ensuring top-notch penetration.

Model Number 721
Series Number D
Configuration
Serial Number 106.25" BUCKET
Blade Position Base Edge With Segment Holes
Blade Thickness 1.25
Blade Width 10
Blade Length 106.3
Hole Quantity 30
Bolt Diameter 1.063
First Hole Distance From End in Inches 4.768
Second Hole Distance From First Hole in Inches 6.283
Third Hole Distance From Second Hole in Inches 3.323
Bolt Quantity for First Row of Holes 0
Bolt Length for First Row of Holes 0
Bolt Quantity for Second Row of Holes 0
Bolt Length for Second Row of Holes 0
Second Set of Holes First Hole Distance From End 14.37
Second Set of Holes Second Hole Distance From First Hole 12.925
Second Set of Holes Third Hole Distance From Second Hole 12.925
