Blades offer unparalleled manufacturing precision, moderate impact resistance, and consistent, superior protection. Made from durable steel, they maintain hardness for long wear life, increase bucket capacity, and reduce downtime. Always choose quality OEM Ground Engaging Tools to protect your investment and improve your machine's performance.
| Model Number | D5 |
|---|---|
| Series Number | |
| Configuration | Angle |
| Serial Number | 91H 96H 42K |
| Blade Position | Hot Cup End Bit RH |
| Blade Thickness | 1.125 |
| Blade Width | 11 |
| Blade Length | 17.75 |
| Hole Quantity | 6 |
| Bolt Diameter | 0.75 |
| First Hole Distance From End in Inches | 2 |
| Second Hole Distance From First Hole in Inches | 3.5 |
| Third Hole Distance From Second Hole in Inches | 3.5 |
| Bolt Quantity for First Row of Holes | 3 |
| Bolt Length for First Row of Holes | 2.25 |
| Bolt Quantity for Second Row of Holes | 3 |
| Bolt Length for Second Row of Holes | 2.25 |
| Second Set of Holes First Hole Distance From End | 2 |
| Second Set of Holes Second Hole Distance From First Hole | 4 |
| Second Set of Holes Third Hole Distance From Second Hole | 4 |
